Cross Fire

Bumper Pull Trailer

The horse trailer with all the basics.  When the "Bells and Whistles" are an after thought and you just need to haul horses, get the strength and quality you need from an Entry Level Logan Coach horse trailer.

360s
GALLERY
PLANS
Features
360° Galleries

Take a look at a high resolution 360° Gallery of this trailer

Crossfire Photo Gallery
Standard Features
DIMENSIONS & Weight
7’0” Tall – 6’9” Wide

2-Horse BP – 2,540 lbs - Tongue Weight – 380 lbs

3-Horse BP – 2,920 lbs - Tongue Weight – 440 lbs
STRUCTURAL
Galva-Strong Galvanized Structural Tubing - Frame Rails, Floor and Wall Uprights

Aluminum Structural Roof Bows

Aluminum Structural Roof Cove
WHEELS, TIRES & AXLES
Torsion Axles

Self-adjusting Brakes

Steel Wheels w/ Center Caps

Radial Tires
2H BP - 225/75/R15 - D Rated 8 Ply
3H BP - 225/75/R15 - D Rated 8 Ply
Exterior
.030 White Smooth Aluminum Wall Sheets

Vortex Rubber Coating on Bumper Pull Tongue

Treadbrite Gravel Guard around Front Wrap

Treadbrite Trim on Bottom of Wall Entire Exterior Length

Rear Rubber Bumper

Exterior Tie Ring - One Each Side Per Stall
ELECTRICAL
Dome Light in Tack Room

LED Marker and Tail Lights

LED Stall Lights
Tack/Dressing Room
33” Wide Tack Door Opening with Pre-fab door

Carpet on Floor

Blanket Bar

Swing-Out Saddle Rack

12 Bridle Hooks

Carpet on Top Half of Bulkhead Wall Behind Bridles
Stall Area
Double Rear Doors w/ Cam Latch

Tailside Air Gap W/ Removable Plexiglass

Pre-fab Drop Down Windows and Grills on Headside of Each Stall

Douglas Fir Wood Floor W/ Vortex Rubber Coating

1/2" Rubber Floor Mats

48” High Double Wall Construction with Vortex Rubber Coating

Padded Divider

Pop-Up Vent Each Stall

48” High Double Wall Construction with Vortex Rubber Coating

Padded Divider

Pop-Up Vent Each Stall

Warranty
8-Year Structural

2-Year Hitch-to-Bumper
